The MFC-J6945DW delivers reliable and high quality performance in demanding office environments. Print, scan and copy up to A3 size. With fast print speeds and first 6 seconds of printout, you don't have to wait for quality prints. Use optional high-capacity inks up to approx. They provide 6,000-page printing and deliver reliable, professional printing to your office.
Featured properties
u00a0
A3 printer, copier, scanner and fax
u00a0
Up to 22fps mono and 20fps color print
u00a0 Automatic Duplex A3 Print, Copy and Scan
u00a09.3 cm color touch screen
u00a0 500 sheet paper capacity | 100-sheet multi-purpose tray | 50-sheet ADF | Automatic "little paper" detection
General presentation
Printer Type Color
u00a0Features Print, Overlay, Scan, Fax
u00a0Display Color Touchscreen
u00a0Display size 9.3cm color LCD
u00a0Max. Paper size A3
u00a0Memory 512MB
u00a0Technology Inkjet
Connectivity Connectivity Wired, Wireless,
u00a0Local Interface Hi-Speed USB 2.0 & USB Host for External Card Reader
u00a0NFC NFC Card Support for Secure Authentication and NFC Supported Mobile Devices
u00a0Wired Network Interface 10Base-T / 100Base-TX
u00a0Wireless Network Interface IEEE 802.11b / g / n
Cell Contacts Supported AirPrint, Cortado Cloud Print, Google Cloud Print 2.0, iPrint & Scan, Brother Print Service Plugin, Mopria
Copy Duplex Copy Yes
u00a0Resolution from Flat up to 600 x 600dpi (color and mono). ADF up to 600 x 600 (mono) and up to 300 x 600 (color)
u00a0Speed 11fps color and 15fps mono
u00a0Zoom / Zoom ratio 25% to 400%, 1% scale
u00a0N-az-1 Yes
Size & Weight
With Dobby 681 (wide) x 576 (me) x 504 (ma) mm
u00a0With box 28.7 kg
u00a0Without box 575 (plain) x 477 (me) x 379 (ma) mm
u00a0Weight 24.2 kg
Environment Sound pressure of 50dB when printing
u00a0Blue Angel environmental certification Yes
u00a0Energy Star Environmental Certification Yes
u00a0Nordic Swan environmental certification Yes
u00a0Power Consumption at 29 W (6.5 Standby, 1.6 Sleep)
Fax Automatic Two-Sided Faxing Yes
u00a0Faxmodem 33600 kb / s
u00a0Internet Fax Yes
u00a0PC Fax Yes
Package Contents
Power Cord, Safety Guide, Software Disk, Supplies, User Manual, Warranty Card, Quick Installation Guide
Media Information
Types and Dimensions Standard Tray - Smooth, Inkjet, Glossy, Recycled (A3, A4, LTR, LGR, LGL, EXE, Folio, A5, A6, Photo (10x15cm / 4x6 "), Indexcard (13x20cm / 5x8") , Photo-L (9x13cm / 3.5x5 "), Photo-2L (13x18cm / 5x7"), C5, Com-10, DL Envelope, Monarch, Mexico Legal, India Legal). ). Bottom Tray - Plain, Recycled (A3, A4, LTR, LGR, LGL, Folio, Mexico Legal, India Legal). Multifunctional Tray - Plain, Inkjet, Glossy, Recycled (A3, A4, LTR, LGR, LGL, EXE, Folio, A5, A6, Photo (10x15cm / 4x6 "), Indexcard (13x20cm / 5x8"), Photo-L (9x13cm) /3.5x5 "), Photo-2L (13x18cm / 5x7"), Com-10, DL Envelope, Monarch 5 C5, Mexico Legal, India Legal). Automatic Document Feeder (ADF) - Plain, Recycled (105 / 148mm - 297 / 431.8mm (4.1 / 5.8 "- 11.7 / 17.0") * Long Paper Length 900mm (35.4 "). 2 Side - Plain, Recycled (A3 / LGR / LGL / Folio / A4 / LTR / EXE / A5 / Mexico Legal / India Legal)
u00a0Weight Standard tray - 64-220g / m2 (17-58 lb), Lower paper tray - 64-120g / m2 (17-32 lb), Multi-purpose tray - 64-220g / m2 (17-58 lb), 2-sided - 64 -120g / m2 (17-32 lb). Automatic Document Feeder - 64-90g / m2 (17-24lb.)
Network Wi-Fi Direct u2122 Yes
u00a0Wired Network 10Base-T / 100Base-TX
u00a0Wired Network Security APOP, SMTP-AUTH, SSL / TLS (IPPS, HTTPS, FTPS, SMTP, POP3, IMAP4), SNMP v3 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos, Ipsec
u00a0Wireless Network IEEE 802.11b / g / n (Infrastructure Mode / Ad-hoc Mode) IEEE 802.11g (Wi-Fi Direct)
u00a0Wireless Network Security APOP, SMTP-AUTH, SSL / TLS (IPPS, HTTPS, FTPS, SMTP, POP3, IMAP4), SNMP v3, 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos, Ipsec. WEP 64/128 bit, WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES) Wi-Fi Direct supports WPA2-PSK (AES) only.
u00a0Support for wireless setting Yes
Operating System and Software
Supported Windows 7, 8, 8.1, 10, Server 2008 & 2008 R2, Server 2012 & 2012 R2. macOS X 10.9.x, 10.10.x, 10.11.x macOS 10.12.x, 10.13.x. Linux CUPS, LPD / LPRng
Paper Handling Paper Input 250-sheet standard paper tray, 250-sheet lower paper tray, 100-sheet multi-purpose tray, 50-sheet automatic document feeder
u00a0Paper Output Up to 100 sheets A4, up to 50 sheets A3
Print Resolution Up to 1,200 x 4.800 dpi
u00a0Speed - Fast Mode Up to 35 ppm Mono & Up to 27 ppm Color
u00a0Speed - 22 images per minute mono & 20 fps color like laser printer according to ISO / IEC 24734
u00a0Automatic Duplexing Yes
u00a0Emulation PCL6, BR-Script3, PDF Version 1.7, XPS Version 1.0
u00a0First Print Time Less than 6 seconds
u00a0Recommended Monthly Volume 250 - 2,000 / Maximum Monthly Print Up to 30,000 Pages
Scanning Duplexing Yes
u00a0Resolution from Plain 1200 x 2400dpi (mono) / 1200 x 1200dpi (color) ADF 600 x 600dpi (mono) / 300 x 600dpi (color)
u00a0Speed A4 portrait 18fps; 18fps, A4 landscape 11fps, 11fps, A3 8fps, 8fps
u00a0Scanner Type Double CIS
Security features
802.1x Yes
u00a0IP Filter Yes
u00a0NFC Yes
u00a0Security function lock, 3.0 Yes
u00a0Secure printing Yes
u00a0Setting Lock Yes
Solutions Supported by PrintSmart CostControl, Brother Web Connect, Brother Apps
Supplies and Optional Accessories
Brother Paper BP71GLA A4 Glossy Photo Paper (20 sheets) BP71GLP 10x15cm Glossy Photo Paper (20/50 sheets)), BP60MA A4 Matte Inkjet Paper (25 sheets), BP60PA A4 Inkjet Paper (250 sheets), BP71GA3 A3 glossy paper (20 sheets), BP60MA3 A3 A3 matte inkjet paper (25 sheets), BP60PA3 A3 inkjet plain paper (250 sheets)
u00a0High Capacity Toner Cartridges LC3239XL Black - 6,000 pages / Cyan, Magenta, Yellow - 5,000 pages
u00a0Standard Capacity Toner Cartridges LC3237 Black - 3,000 pages / Cyan, Magenta, Yellow - 1,500 pages
Warranty Warranty 2 plus one year * (based on registration)
** Brother MFCJ6945DW MFP ** * A3 print / scan / copy / fax * DUPLEX, TOUCH SCREEN, WIRELESS NETWORK COLOR INKJET PRINTER / FAX / COPIER / SCANNER * 50-sheet DSDF, * 2 x 250-sheet paper tray, * 512MB RAM. * Printer: 600x1200 dpi, 22/20 pages per minute, 9.3 cm LCD touch screen. * Fax: 33600 bps, * Interface: USB 2.0, Ethernet 10/100, Wireless 802.11b / g / n, WiFi direct, NFC, * Photo Capture center: Direct printing from USB stick and memory card, borderless printing. * Scanner: 1200X2400 dpi. * Starting line: LC3237 line. * Supplies: LC-3237 Bk 3000, C / M / Y 1500pld LC3239XL Bk: 6000, C / M / Y: 5000 pld
